MATRIX RT: Online Single-Phase UPS (6-10kVA)

from €1,703.00

The MATRIX RT 6–10 kVA series offers top-tier GTEC online single-phase UPS performance, delivering high-efficiency, reliable power protection for demanding applications. These systems are designed for critical IT, industrial, and commercial environments.

Warranty – All GTEC UPS systems include a 1-year manufacturer’s warranty, ensuring dependable performance and peace of mind from day one.

High Efficiency – Achieves up to 95% efficiency in Normal Mode with Power Factor 1, optimising energy use and reducing operational costs.

Flexible Design – Rack/tower convertible design allows versatile installation while optimising space and airflow.

Reliability – Engineered with advanced components for long-lasting operation and superior protection against power fluctuations.

Advanced Communication – Standard RS232 and USB connectivity, optional SNMP/MODBUS/AS400 cards, plus real-time monitoring via the GTEC Explore mobile app, showing UPS status, load, autonomy, and voltage for all connected units.

UPS Rating:

Communication:

Quantity:

Warranty – All GTEC UPS systems include a 1-year manufacturer’s warranty, ensuring dependable performance and peace of mind from day one.

High Efficiency – Achieves up to 95% efficiency in Normal Mode with Power Factor 1, optimising energy use and reducing operational costs.

Flexible Design – Rack/tower convertible design allows versatile installation while optimising space and airflow.

Reliability – Engineered with advanced components for long-lasting operation and superior protection against power fluctuations.

Technical Specifications

MATRIX RT is available in the sizes 1, 2, 3, 6, 10 kVA.


    Model
    MXT6K0MM
    MXT010MM

    Power
    6 KVA / 6 KW
    10 KVA / 10 KW

	MAIN INPUT

    Grid System
    1 PH + N + PE

    Rated Voltage / Frequency
    220/230/240 VAC, 50/60 Hz

    Volted Range
    160-275 V 100% load, 110-160 V derating to 50% load linearly

    Rated Current**
    35 A
    54 A

    Frequency Range
    ≤60% rated load: 40-70 Hz
Rated load: 45-55 Hz (50 Hz system) / 54-66 Hz (60 Hz system)

    Power Factor
    >0,99

    Current THDi
   ><3% Linear load
<5% non linear load

	OUTPUT

    Rated Voltage / Frequency
    >220/230/240 VAC, 50/60 Hz

    Power Factor
    1

    Wave Form
    Pure sine wave

    Voltage THDv
    <1% (linear load);
<5% (non-linear load)

    Voltage Accuracy
    ±1%

    Transient Recovery
    Compliant to EN62040-3 VFI-SS-111 Standard

    Inverter Overload
    100% < load ≤ 105%, continuous
105% < load ≤ 125%, 10 minute
125 < load ≤ 150%, 30 seconds
> 150%, 500 ms

    Bypass Overload
    100% < load ≤ 105%, continuous
105% < load ≤ 125%, 10 minute
125 < load ≤ 150%, 30 seconds
> 150%, 500 ms

    Frequency Regulation (Battery Mode)
    50/60 Hz ±0.1%

    Crest Factor
    3:1

	BATTERIES

    Battery Type
    Pb

    Battery Capacity
    12 V / 7 Ah
    12 V / 9 Ah

    Number of Batteries in Series
    16***
    20***

    Battery Rate Voltage
    192 VDC
    240 VDC

    Backup time (20 Battery)****
    6 min full load
9 min typical load
    7 min full load
9 min typical load

	BATTERY CHARGER

    Charging Current
    Range: 1~4 A
Default: 1,4 A
 Range: 1~4 A
Default: 2 A

    Charging Time (2.1 A recharging current)
    3 h to recover
90% capacity

	SYSTEM

    Efficiency
    Normal operation: 94.9%
Eco Mode operation: 98.6%
Battery operation: 92.9%
    Normal operation: 94.6%
Eco Mode operation: 98.7%
Battery operation: 91.8%

    Display
    LCD

    Protection Degree
    IP20

    Interface
    Standard equipment: USB, RS232, RS485, RPO, Intelligent slot
Optional: SNMP, dry contacts, parallel kit, Modbus

	ENVIRONMENT

    Operating Temperature
    0°C ~ 50°C (Derating 50% above 40°C)

    Storage Temperature
    -15°C ~ 40°C (with battery, suggest to storage the battery below 25°C)
-25°C ~ 55°C (without battery)

    Relative Humidity
    0 ~ 95% (no condensing)

    Noise (dBA at 1 meter far)
    <50 dB
    <55 dB

    Altitude
    0 ~ 3000 m; load derated 1% per 100m, from 1000 ~ 3000m

	MECHANICAL DATA

    Dimensions W*D*H (mm)
    438*559* 215(5U)
UPS + Battery cabinet
    438*559* 215(5U)
UPS + Battery cabinet

    Weight (KG)
    59,4
UPS + Battery cabinet
    76,2
UPS + Battery cabinet

    Colour
    Black
