MATRIX: Advanced Single-Phase UPS (6-10 kVA)

from €1,548.00

The MATRIX series delivers premium online single-phase UPS protection with a high-performance design for demanding applications. Available in 6 and 10 kVA (1/1 configuration) and 10 kVA (3/1 configuration), these systems combine cutting-edge technology with reliability and efficiency.

Optimised Battery Management – High-power chargers allow fast recharging; the KS version supports external battery cabinets for extended runtime, with auto-sensing for accurate autonomy calculation.

High Efficiency – Up to 95% in Normal Mode with Power Factor 1, reducing operating costs and maximising energy use.

Reliability – Built with advanced components for long-lasting performance and significantly higher MTBF.

Smart Communication – Standard RS232 and USB ports, optional SNMP/MODBUS/AS400, plus real-time monitoring via the GTEC Explore app.

UPS Rating:

Communication:

Quantity:

High Efficiency – Up to 95% in Normal Mode with Power Factor 1, reducing operating costs and maximising energy use.

Reliability – Built with advanced components for long-lasting performance and significantly higher MTBF.

Smart Communication – Standard RS232 and USB ports, optional SNMP/MODBUS/AS400, plus real-time monitoring via the GTEC Explore app.

Technical Specifications

MATRIX is available in the sizes 1, 2, 3, 6, 10 kVA with 1/1 configuration and in the size 10 kVA with 3/1 configuration.


    Model
    MXT6K0MM
    MXT010MM
    MXT010TM*

    Power
    6 KVA / 6 KW
    10 KVA / 10 KW
    10 KVA / 10 KW

	MAIN INPUT

    Grid System
    1 PH + N + PE
        3 PH + N + PE

    Rated Voltage / Frequency
    220/230/240 VAC, 50/60 Hz

    Volted Range
    160-275 V 100% load, 110-160 V derating to 50% load linearly

    Rated Current**
    35 A
    54 A
    54 A (1-1)
L1 48 A - L2/L3 18 A
(3-1)

    Frequency Range
    ≤60% rated load: 40-70 Hz
Rated load: 45-55 Hz (50 Hz system) / 54-66 Hz (60 Hz system)

    Power Factor
    >0,99
    >0,95

    Current THDi
   ><3% Linear load
<5% non linear load
    ><30% at 3 phase input
<5% at 1 phase input

	OUTPUT

    Rated Voltage / Frequency
    >220/230/240 VAC, 50/60 Hz

    Power Factor
    1

    Wave Form
    Pure sine wave

    Voltage THDv
    <1% (linear load);
<5% (non-linear load)

    Voltage Accuracy
    ±1%

    Transient Recovery
    Compliant to EN62040-3 VFI-SS-111 Standard

    Inverter Overload
    100% < load ≤ 105%, continuous
105% < load ≤ 125%, 10 minute
125 < load ≤ 150%, 30 seconds
> 150%, 500 ms

    Bypass Overload
    100% < load ≤ 105%, continuous
105% < load ≤ 125%, 10 minute
125 < load ≤ 150%, 30 seconds
> 150%, 500 ms

    Frequency Regulation (Battery Mode)
    50/60 Hz ±0.1%

    Crest Factor
    3:1

	BATTERIES

    Battery Type
    Pb

    Battery Capacity
    12 V / 7 Ah
    12 V / 9 Ah
    12 V / 9 Ah

    Number of Batteries in Series
    20***

    Battery Rate Voltage
    240 VDC

    Backup time (20 Battery)****
    9 min full load
13 min typical load
    7 min full load
9 min typical load
    7 min full load
9 min typical load

	BATTERY CHARGER

    Charging Current
    Range: 1~4 A
Default: 1,4 A
 Range: 1~4 A
Default: 2 A
 Range: 1~4 A
Default: 2 A

    Charging Time (2.1 A recharging current)
    3 h to recover
90% capacity

	SYSTEM

    Efficiency
    Normal operation: 94.9%
Eco Mode operation: 98.6%
Battery operation: 92.9%
    Normal operation: 94.6%
Eco Mode operation: 98.7%
Battery operation: 91.8%
 Normal operation: 94.6%
Eco Mode operation: 98.8%
Battery operation: 91.8%

    Display
    LCD

    Protection Degree
    IP20

    Interface
    Standard equipment: USB, RS232, RS485, RPO, Intelligent slot
Optional: SNMP, dry contacts, parallel kit, Modbus

	ENVIRONMENT

    Operating Temperature
    0°C ~ 50°C (Derating 50% above 40°C)

    Storage Temperature
    -15°C ~ 40°C (with battery, suggest to storage the battery below 25°C)
-25°C ~ 55°C (without battery)

    Relative Humidity
    0 ~ 95% (no condensing)

    Noise (dBA at 1 meter far)
    <45 dB
    <50 dB

    Altitude
    0 ~ 3000 m; load derated 1% per 100m, from 1000 ~ 3000m

	MECHANICAL DATA

    Dimensions W*D*H (mm)
    225*416*589
    225*416*589
       225*416*589

    Weight (KG)
    57.9 (20 batteries)
    68.2 (20 batteries)
    68.7 (20 batteries)

    Colour
    Black
